X 光下可顯影擴張器具親水塗層-單件式-經皮引流導管附屬配件

以聚氨酯、聚乙烯製造, X光下可顯影。
符合ISO規範盧耳接頭。
表面具親水塗層。
採用無菌消毒袋包裝, 限一次性使用。

產品線圖

規格

UR:Polyurethane with Radiopaque

型號	尺寸	擴張管容許最大導絲線徑	工作長度	型號	尺寸	擴張管容許最大導絲線徑
DR-UR-1P-0505-28	5F	0.28"inch (0.71mm)	05cm(xx=05)	DR-UR-1P-1005-38	10F	0.38"inch(0.97mm)
DR-UR-1P-0510-28	5F	0.28"inch (0.71mm)	10cm(xx=10)	DR-UR-1P-1010-38	10F	0.38"inch(0.97mm)
DR-UR-1P-0515-28	5F	0.28"inch (0.71mm)	15cm(xx=15)	DR-UR-1P-1015-38	10F	0.38"inch(0.97mm)
DR-UR-1P-0520-28	5F	0.28"inch (0.71mm)	20cm(xx=20)	DR-UR-1P-1020-38	10F	0.38"inch(0.97mm)
DR-UR-1P-0525-28	5F	0.28"inch (0.71mm)	25cm(xx=25)	DR-UR-1P-1025-38	10F	0.38"inch(0.97mm)
DR-UR-1P-0505-35	5F	0.35"inch(0.89mm)	05cm(xx=05)	DR-UR-1P-1105-38	11F	0.38"inch(0.97mm)
DR-UR-1P-0510-35	5F	0.35"inch(0.89mm)	10cm(xx=10)	DR-UR-1P-1110-38	11F	0.38"inch(0.97mm)
DR-UR-1P-0515-35	5F	0.35"inch(0.89mm)	15cm(xx=15)	DR-UR-1P-1115-38	11F	0.38"inch(0.97mm)
DR-UR-1P-0520-35	5F	0.35"inch(0.89mm)	20cm(xx=20)	DR-UR-1P-1120-38	11F	0.38"inch(0.97mm)
DR-UR-1P-0525-35	5F	0.35"inch(0.89mm)	25cm(xx=25)	DR-UR-1P-1125-38	11F	0.38"inch(0.97mm)
DR-UR-1P-0505-38	5F	0.38"inch(0.97mm)	05cm(xx=05)	DR-UR-1P-1305	13F	0.038 inch(0.97mm)
DR-UR-1P-0510-38	5F	0.38"inch(0.97mm)	10cm(xx=10)	DR-UR-1P-1310	13F	0.038 inch(0.97mm)
DR-UR-1P-0515-38	5F	0.38"inch(0.97mm)	15cm(xx=15)	DR-UR-1P-1315	13F	0.038 inch(0.97mm)
DR-UR-1P-0520-38	5F	0.38"inch(0.97mm)	20cm(xx=20)	DR-UR-1P-1320	13F	0.038 inch(0.97mm)
DR-UR-1P-0525-38	5F	0.38"inch(0.97mm)	25cm(xx=25)	DR-UR-1P-1325	13F	0.038 inch(0.97mm)
DR-UR-1P-0605	6F	0.38"inch(0.97mm)	05cm(xx=05)	DR-UR-1P-1405	14F	0.038 inch(0.97mm)
DR-UR-1P-0610	6F	0.38"inch(0.97mm)	10cm(xx=10)	DR-UR-1P-1410	14F	0.038 inch(0.97mm)
DR-UR-1P-0615	6F	0.38"inch(0.97mm)	15cm(xx=15)	DR-UR-1P-1415	14F	0.038 inch(0.97mm)
DR-UR-1P-0620	6F	0.38"inch(0.97mm)	20cm(xx=20)	DR-UR-1P-1420	14F	0.038 inch(0.97mm)
DR-UR-1P-0625	6F	0.38"inch(0.97mm)	25cm(xx=25)	DR-UR-1P-1425	14F	0.038 inch(0.97mm)
DR-UR-1P-0705	7F	0.38"inch(0.97mm)	05cm(xx=05)	DR-UR-1P-1505	15F	0.038 inch(0.97mm)
DR-UR-1P-0710	7F	0.38"inch(0.97mm)	10cm(xx=10)	DR-UR-1P-1510	15F	0.038 inch(0.97mm)
DR-UR-1P-0715	7F	0.38"inch(0.97mm)	15cm(xx=15)	DR-UR-1P-1515	15F	0.038 inch(0.97mm)
DR-UR-1P-0720	7F	0.38"inch(0.97mm)	20cm(xx=20)	DR-UR-1P-1520	15F	0.038 inch(0.97mm)
DR-UR-1P-0725	7F	0.38"inch(0.97mm)	25cm(xx=25)	DR-UR-1P-1525	15F	0.038 inch(0.97mm)
DR-UR-1P-0805-35	8F	0.38"inch(0.97mm)	05cm(xx=05)	DR-UR-1P-1605	16F	0.038 inch(0.97mm)
DR-UR-1P-0810-35	8F	0.38"inch(0.97mm)	10cm(xx=10)	DR-UR-1P-1610	16F	0.038 inch(0.97mm)
DR-UR-1P-0815-35	8F	0.38"inch(0.97mm)	15cm(xx=15)	DR-UR-1P-1615	16F	0.038 inch(0.97mm)
DR-UR-1P-0820-35	8F	0.38"inch(0.97mm)	20cm(xx=20)	DR-UR-1P-1620	16F	0.038 inch(0.97mm)
DR-UR-1P-0825-35	8F	0.38"inch(0.97mm)	25cm(xx=25)	DR-UR-1P-1625	16F	0.038 inch(0.97mm)
DR-UR-1P-0805-38	8F	0.38"inch(0.97mm)	05cm(xx=05)
DR-UR-1P-0810-38	8F	0.38"inch(0.97mm)	10cm(xx=10)
DR-UR-1P-0815-38	8F	0.38"inch(0.97mm)	15cm(xx=15)
DR-UR-1P-0820-38	8F	0.38"inch(0.97mm)	20cm(xx=20)
DR-UR-1P-0825-38	8F	0.38"inch(0.97mm)	25cm(xx=25)
DR-UR-1P-0905-38	9F	0.38"inch(0.97mm)	05cm(xx=05)
DR-UR-1P-0910-38	9F	0.38"inch(0.97mm)	10cm(xx=10)
DR-UR-1P-0915-38	9F	0.38"inch(0.97mm)	15cm(xx=15)
DR-UR-1P-0920-38	9F	0.38"inch(0.97mm)	20cm(xx=20)
DR-UR-1P-0925-38	9F	0.38"inch(0.97mm)	25cm(xx=25)

註: 無國際CE認證

ER:Polyethylene with Radiopaque

型號	尺寸	擴張管容許最大導絲線徑	工作長度
DR-ER-1P-1505	15F	0.038 inch (0.97mm)	05 cm (XX=05)
DR-ER-1P-1510	15F	0.038 inch (0.97mm)	10 cm (XX=10)
DR-ER-1P-1515	15F	0.038 inch (0.97mm)	15 cm (XX=15)
DR-ER-1P-1520	15F	0.038 inch (0.97mm)	20 cm (XX=20)
DR-ER-1P-1525	15F	0.038 inch (0.97mm)	25 cm (XX=25)
DR-ER-1P-1605	16F	0.038 inch (0.97mm)	05 cm (XX=05)
DR-ER-1P-1610	16F	0.038 inch (0.97mm)	10 cm (XX=10)
DR-ER-1P-1615	16F	0.038 inch (0.97mm)	15 cm (XX=15)
DR-ER-1P-1620	16F	0.038 inch (0.97mm)	20 cm (XX=20)
DR-ER-1P-1625	16F	0.038 inch (0.97mm)	25 cm (XX=25)

註: 無國際CE認證
